Technical details | |
Vendor | APC by Schneider Electric |
Packaging content | |
Software CD | Y |
Cables included | Phone (RJ-11), USB cable |
Bundled software | PowerChute Personal Edition |
Manual | Y |
Warranty card | Y |
Ports & interfaces | |
Cable length | 1.83 m |
Number of type F outputs | 6 |
USB port | N |
AC outlet types | Type F |
Weight & dimensions | |
Height | 301 mm |
Width | 112 mm |
Depth | 382 mm |
Package depth | 490 mm |
Package height | 390 mm |
Package width | 235 mm |
Package weight | 13800 g |
Weight | 13000 g |
Battery | |
Battery recharge time | 8 h |
Typical backup time at half load | 15.7 min |
Typical backup time at full load | 5.4 min |
Replacement battery cartridge | APCRBC124 |
Battery technology | Sealed Lead Acid (VRLA) |
Cold start | Y |
Automatic battery test | Y |
Battery capacity | 187 VAh |
Other features | |
Nominal output voltage | 230 V |
Nominal input voltage | 230 V |
Design | |
Product colour | Black |
Display | LCD |
Performance | |
Waveform | Sine |
Automatic Voltage Regulation (AVR) | Y |
LED indicators | Y |
Audible alarm(s) | Y |
UPS topology | Line-Interactive |
Noise level | 45 dB |
Hold time (min) | 10 ms |
Hold time (max) | 12 ms |
Surge protection | Y |
Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network |
Power | |
Output frequency regulation | 50/60 Hz |
Power supply input frequency | 50/60 Hz |
Output power capacity | 1200 VA |
Surge energy rating | 441 J |
Maximum current | 10 A |
Efficiency | 98.8 % |
Output power | 720 W |
Input operation voltage (max) | 300 V |
Input operation voltage (min) | 156 V |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Non-operating altitude | 0 – 15000 m |
Operating altitude | 0 – 3000 m |
Operating relative humidity (H-H) | 0 – 95 % |
Storage temperature (T-T) | -15 – 45 °C |
Certificates | |
Certification | BSI 1363, CE, NEMKO, REACH |
RoHS compliance | Y |
Energy efficiency according to EnergyStar 8.0 | Y |
