Technical details | |
Vendor | APC by Schneider Electric |
Sustainability certificates | Green Premium |
Compliance certificates | RoHS |
Ports & interfaces | |
Serial interface type | RJ-45 |
Serial interface | Yes |
USB port | Yes |
SmartSlot | Yes |
Weight & dimensions | |
Height | 432 mm |
Width | 85 mm |
Depth | 505 mm |
Package depth | 749 mm |
Package height | 246 mm |
Package width | 594 mm |
Package weight | 29600 g |
Weight | 20500 g |
Battery | |
Battery recharge time | 3 h |
Battery life (max) | 5 year(s) |
Hot-swap battery | Yes |
Battery technology | Sealed Lead Acid (VRLA) |
Design | |
Cable length | 1.83 m |
LED indicators | Yes |
Product colour | Black |
Certification | CE, EAC |
Form factor | Rackmount/Tower |
International Protection (IP) code | IP20 |
Display type | LCD |
Features | |
Waveform | Sine |
Audible alarm(s) | Yes |
UPS topology | Double-conversion (Online) |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1.5 kVA |
Surge energy rating | 432 J |
Noise level | 50 dB |
Input frequency | 40/70 Hz |
Output power | 1500 W |
Crest factor | 3:1 |
Input operation voltage (max) | 275 V |
Input operation voltage (min) | 100 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Output frequency | 50/60 Hz |
Logistics data | |
Harmonized System (HS) code | 85078000 |
Products per pallet | 12 pc(s) |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Operating relative humidity (H-H) | 0 – 95 % |
Storage temperature (T-T) | -20 – 50 °C |
Packaging data | |
Manual | Yes |
