Processor | |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
Processor socket | LGA 1700 |
Memory | |
Memory slots type | DIMM |
Maximum internal memory | 64 GB |
Number of memory slots | 2 |
Non-ECC | Y |
Supported memory clock speeds | 2133.2400.2666.2800.2933.3000.3200 MHz |
Supported memory types | DDR4-SDRAM, LPDDR3-SDRAM |
Memory channels | Dual-channel |
Unbuffered memory | Y |
Network | |
Ethernet LAN | Y |
Wake-on-LAN ready | Y |
Wi-Fi | N |
Ethernet interface | Gigabit Ethernet |
Technical details | |
Vendor | Asustek |
Packaging content | |
Cables included | SATA |
Expansion slots | |
PCI Express x1 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 1 |
BIOS | |
BIOS memory size | 128 Mbit |
BIOS type | UEFI AMI |
Weight & dimensions | |
Height | 221 mm |
Width | 244 mm |
Depth | 211 mm |
Other features | |
Weight | 382 g |
Features | |
Motherboard form factor | micro ATX |
Audio output channels | 7.1 channels |
Motherboard chipset | Intel H610 |
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
Motherboard chipset family | Intel |
Component for | PC |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Internal I/O | |
12V power connector | Y |
USB 2.0 connectors | 1 |
S (B 2.0 connectors – PDIF out connector – B 3.2 Gen 1 (3.1 Gen 1) connectors – mber of SATA III connectors) | 1 – Y – 1 – 4 |
CPU fan connector | Y |
Number of COM connectors | 1 |
ATX Power connector (24-pin) | Y |
Number of chassis fan connectors | 2 |
Front panel audio connector | Y |
TPM connector | Y |
RGB LED pin header | Y |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 4 |
Rear panel I/O ports | |
DisplayPort version | 1.4 |
PS (2 ports quantity) | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
VGA (D-Sub) ports quantity | 1 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 1 |
Storage controllers | |
Supported storage drive types | HDD & SSD |
Storage interfaces | M.2, SATA III |
