Processor | |
Processor manufacturer | Intel |
Compatible processor series | Intel Xeon W |
Processor socket | LGA 4677 |
Intel Xeon series | W-3400, W-2400 |
Memory | |
Memory slots type | DIMM |
Maximum internal memory | 2048 GB |
ECC | Y |
Number of memory slots | 8 |
Supported memory clock speeds | 4800.5000.5200.5400.5600.5800.6000.6200.6400.6600.6800 MHz |
Supported memory types | DDR5-SDRAM |
Memory channels | Quad-channel |
Network | |
Ethernet LAN | Y |
Wi-Fi | N |
Ethernet interface | 2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
Technical details | |
Vendor | Asustek |
Expansion slots | |
PCI Express x16 (Gen 5.x) slots | 5 |
BIOS | |
BIOS memory size | 512 Mbit |
BIOS type | UEFI AMI |
Clear CMOS button | Y |
Weight & dimensions | |
Height | 50 mm |
Width | 305 mm |
Depth | 277 mm |
Other features | |
Weight | 1814 g |
Features | |
Audio output channels | 7.1 channels |
Audio chip | Realtek S1220A |
Motherboard chipset | Intel W790 |
Windows operating systems supported | Windows 10 x64, Windows 11 |
Motherboard chipset family | Intel |
Component for | Workstation |
Internal I/O | |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Y |
USB 2.0 connectors | 2 |
CPU fan connector | Y |
Number of COM connectors | 1 |
ATX Power connector (24-pin) | Y |
Number of chassis fan connectors | 5 |
Front panel audio connector | Y |
TPM connector | Y |
EPS power connector (8-pin) | Y |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 4 |
Rear panel I/O ports | |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
USB 2.0 ports quantity | 8 |
Ethernet LAN (RJ-45) ports | 2 |
Headphone outputs | 1 |
Microphone in | Y |
S (B 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity – B 2.0 ports quantity – PDIF out port – B 3.2 Gen 2×2 Type-C ports quantity) | 4 – 8 – Y – 1 |
USB 3.2 Gen 2×2 Type-C ports quantity | 1 |
Storage controllers | |
RAID levels | 0, 1, 5, 10 |
Supported storage drive types | HDD & SSD |
Storage interfaces | M.2, SATA III |
Number of HDDs supported | 4 |
RAID support | Y |
Number of storage drives supported | 6 |
Packaging data | |
Package depth | 312 mm |
Package height | 108 mm |
Package width | 370 mm |
Package weight | 3515 g |
