Processor | |
Processor cores | 24 |
Processor cache | 36 MB |
Processor manufacturer | Intel |
Processor codename | Raptor Lake |
Processor cache type | Smart Cache |
Processor family | Intel® Core™ i9 |
Memory bandwidth supported by processor (max) | 89.6 GB/s |
Box | Yes |
Processor socket | LGA 1700 |
Processor ARK ID | 236773 |
Stepping | B0 |
Efficient cores | 16 |
Performance cores | 8 |
Maximum number of DMI lanes | 8 |
Processor base power | 125 W |
Maximum turbo power | 253 W |
Efficient-core base frequency | 2.4 GHz |
Efficient-core boost frequency | 4.4 GHz |
Performance-core base frequency | 3.2 GHz |
Performance-core boost frequency | 5.6 GHz |
Processor generation | Intel Core i9-14xxx |
Processor model | i9-14900K |
Processor threads | 32 |
Processor operating modes | 64-bit |
Processor boost frequency | 6 GHz |
Technical details | |
Vendor | Intel |
OpenCL version | 3.0 |
Status | Launched |
Launch date | Q4’23 |
Weight & dimensions | |
Processor package size | 45 x 37.5 mm |
Other features | |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
Maximum internal memory | 192 GB |
L2 cache | 32768 KB |
Graphics | |
On-board graphics card base frequency | 300 MHz |
On-board graphics card dynamic frequency (max) | 1650 MHz |
On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
Number of execution units | 32 |
On-board graphics card ID | 0xA780 |
On-board graphics card maximum resolution (eDP – Integrated Flat Panel) | 5120 x 3200 pixels |
On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 120 Hz |
On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
Number of displays supported (on-board graphics) | 4 |
On-board graphics adapter maximum resolution | 4096 x 2160 pixels |
On-board graphics card DirectX version | 12.0 |
On-board graphics card OpenGL version | 4.5 |
Discrete graphics card | No |
Multi-Format Codec Engines | 2 |
On-board graphics card model | Intel UHD Graphics 770 |
Discrete graphics card model | Not available |
On-board graphics card | Yes |
Processor special features | |
Intel® Quick Sync Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel® Secure Key | Yes |
Intel 64 | Yes |
Intel® OS Guard | Yes |
Intel Virtualization Technology for Directed I (O (VT-d)) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Turbo Boost Max Technology 3.0 | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Boot Guard | Yes |
Intel® Thermal Velocity Boost | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Thermal Velocity Boost Frequency | 6 GHz |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.8 GHz |
Intel® Thread Director | Yes |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Adaptive Boost Technology | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Features | |
Execute Disable Bit | Yes |
Idle States | Yes |
Thermal Monitoring Technologies | Yes |
Scalability | 1S |
CPU configuration (max) | 1 |
Embedded options available | No |
PCI Express configurations | 1×16+1×4, 2×8+1×4 |
Thermal solution specification | PCG 2020A |
Maximum number of PCI Express lanes | 20 |
Market segment | Desktop |
Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Use conditions | Workstation, PC/Client/Tablet |
Direct Media Interface (DMI) Revision | 4.0 |
PCI Express slots version | 4.0, 5.0 |
Logistics data | |
Harmonized System (HS) code | 8542310001 |
Operational conditions | |
Tjunction | 100 °C |
Memory | |
ECC | Yes |
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
Memory bandwidth (max) | 89.6 GB/s |
Memory channels | Dual-channel |
