Network | |
Auto-negotiation | Yes |
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x |
Flow control support | Yes |
Port mirroring | Yes |
Link aggregation | Yes |
Broadcast storm control | Yes |
Rate limiting | Yes |
Ethernet LAN data rates | 10.100.1000 Mbit/s |
Virtual LAN features | Port-based VLAN |
Half duplex | Yes |
Full duplex | Yes |
Auto MDI (MDI-X) | Yes |
Number of VLANs | 128 |
Spanning tree protocol | Yes |
Head-of-line (HOL) blocking | Yes |
VLAN support | Yes |
10G support | No |
Technical details | |
Vendor | D-Link |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Weight & dimensions | |
Height | 44 mm |
Width | 280 mm |
Depth | 180 mm |
Weight | 1320 g |
Design | |
LED indicators | Yes |
Product colour | Black, Grey |
Certification | FCC, CE, VCCI, C-Tick, BSMI, CCC |
Rack mounting | Yes |
Form factor | 1U |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | No |
Performance | |
Mean time between failures (MTBF) | 424762 h |
Flash memory | 16 MB |
Power | |
Power source | AC |
Number of power supply units | 1 |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
Power consumption (max) | 15.9 W |
Power supply included | Yes |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | BSMI, CB, CCC, cUL |
Operational conditions | |
Operating temperature (T-T) | -5 – 50 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Heat dissipation | 54.3 BTU/h |
Operating relative humidity (H-H) | 0 – 95 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Packet buffer memory | 4.1 MB |
Switching capacity | 48 Gbit/s |
Jumbo frames | 9216 |
Jumbo frames support | Yes |
MAC address table | 8000 entries |
Forwarding rate | 35.71 Mpps |
Security | |
Loop protection | Yes |
IGMP snooping | Yes |
Management features | |
Switch layer | L2 |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch type | Managed |
