Network | |
Networking standards | IEEE 802.1D, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af |
Flow control support | Yes |
Full duplex | Yes |
Spanning tree protocol | Yes |
Head-of-line (HOL) blocking | Yes |
VLAN support | Yes |
10G support | Yes |
Technical details | |
Vendor | D-Link |
Pallet gross width | 1200 mm |
Pallet gross length | 1100 mm |
Shipping (inner) case width | 346 mm |
Shipping (inner) case length | 382 mm |
Shipping (inner) case height | 317 mm |
Shipping (inner) case gross weight | 11572 g |
Products per shipping (inner) case | 5 pc(s) |
Shipping (inner) case net weight | 10845 g |
Pallet gross weight (air) | 436092 g |
Master (outer) cases per pallet (air) | 36 pc(s) |
Products per pallet (air) | 180 pc(s) |
Pallet height (air) | 1403 mm |
Pallet gross weight (sea) | 644888 g |
Master (outer) cases per pallet (sea) | 54 pc(s) |
Products per pallet (sea) | 270 pc(s) |
Pallet height (sea) | 2037 mm |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 8 |
SFP module slots quantity | 2 |
Weight & dimensions | |
Height | 44 mm |
Width | 280 mm |
Depth | 180 mm |
Other features | |
Packet transfer speed | 14.9 Mp/s |
Power LED | Yes |
Design | |
LED indicators | Yes |
Product colour | Black |
Certification | CE Class A |
Cable management | Yes |
Stackable | Yes |
Rack mounting | Yes |
Safety | cUL, LVD |
Power over Ethernet (PoE) | |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Power over Ethernet (PoE) | Yes |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Multicast features | |
Multicast support | Yes |
Power | |
AC input voltage | 100 – 240 V |
Operational conditions | |
Operating temperature (T-T) | -5 – 50 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Operating relative humidity (H-H) | 0 – 95 % |
Storage temperature (T-T) | -20 – 70 °C |
Protocols | |
Data link protocols | IP |
Management protocols | SNMP, RMON |
Data transmission | |
Packet buffer memory | 6 MB |
Switching capacity | 20 Gbit/s |
Jumbo frames support | Yes |
MAC address table | 16000 entries |
Packaging data | |
Package depth | 331 mm |
Package height | 72 mm |
Package width | 288 mm |
Package weight | 2169 g |
Security | |
MAC address filtering | Yes |
Static port security | Yes |
Access Control List (ACL) | Yes |
DHCP features | DHCP server, DHCP client |
SSH (SSL support) | Yes |
IGMP snooping | Yes |
Management features | |
MIB support | 1213 MIB II, 1493 Bridge MIB, 1907 SNMP v2 MIB, 1215 Trap Convention MIB, 2233 Interface Group MIB, D-Link Private MIB, Power-Ethernet MIB, LLDP MIB, D-Link ZoneDefense MIB1 |
Switch layer | L2 |
Quality of Service (QoS) support | Yes |
Switch type | Managed |
