Network | |
Auto-sensing | Y |
Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3ad,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
Flow control support | Y |
Port mirroring | Y |
Link aggregation | Y |
Full duplex | Y |
Auto MDI (MDI-X) | Y |
Spanning tree protocol | Y |
VLAN support | Y |
10G support | N |
Technical details | |
Vendor | Hewlett Packard |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
SFP module slots quantity | 2 |
Weight & dimensions | |
Height | 43.9 mm |
Width | 215.9 mm |
Depth | 443 mm |
Weight | 2490 g |
Design | |
Rack mounting | Y |
Form factor | 1U |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | N |
Performance | |
Processor model | ARM Cortex-A9 |
Processor frequency | 800 MHz |
Flash memory | 256 MB |
Internal memory | 512 MB |
Memory type | SDRAM |
Built-in processor | Y |
Power | |
Power source | AC |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
Power consumption (max) | 7.8 W |
Power supply included | Y |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 15 – 95 % |
Operating relative humidity (H-H) | 15 – 95 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Packet buffer memory | 1.5 MB |
Latency (10-100 Mbps) | 5.2 µs |
Latency (1 Gbps) | 2.8 µs |
Throughput | 38.68 Mpps |
Switching capacity | 52 Gbit/s |
Jumbo frames support | Y |
MAC address table | 16000 entries |
Security | |
DHCP features | DHCP client |
SSH (SSL support) | Y |
IGMP snooping | Y |
Management features | |
Switch layer | L2 |
Quality of Service (QoS) support | Y |
Web-based management | Y |
Switch type | Managed |
Cloud-managed | Y |
