Network | |
Auto-sensing | Yes |
Networking standards | IEEE 802.1D, IEEE 802.1Qaz, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Flow control support | Yes |
Port mirroring | Yes |
Link aggregation | Yes |
Rate limiting | Yes |
Full duplex | Yes |
Auto MDI (MDI-X) | Yes |
Spanning tree protocol | Yes |
VLAN support | Yes |
10G support | Yes |
Technical details | |
Vendor | Hewlett Packard |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
SFP+ module slots quantity | 4 |
Weight & dimensions | |
Height | 43.9 mm |
Width | 442.5 mm |
Depth | 264.7 mm |
Weight | 3490 g |
Design | |
Product colour | White |
Stackable | No |
Rack mounting | Yes |
Form factor | 1U |
Power over Ethernet (PoE) | |
Total Power over Ethernet (PoE) budget | 195 W |
Power over Ethernet (PoE) | Yes |
Performance | |
Processor model | ARM Cortex-A9 |
Processor frequency | 800 MHz |
Flash memory | 256 MB |
Internal memory | 512 MB |
Memory type | SDRAM / Flash |
Built-in processor | Yes |
Power | |
Power source | AC |
AC input frequency | 50 – 60 Hz |
AC input voltage | 100 – 240 V |
Power consumption (max) | 280 W |
Power supply included | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 15 – 95 % |
Operating altitude | 0 – 3048 m |
Operating relative humidity (H-H) | 15 – 95 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Packet buffer memory | 1.5 MB |
Latency (10-100 Mbps) | 4.7 µs |
Latency (1 Gbps) | 2.4 µs |
Latency (10 Gbps) | 1.3 µs |
Throughput | 95.23 Mpps |
Switching capacity | 128 Gbit/s |
Jumbo frames support | Yes |
MAC address table | 16000 entries |
Security | |
Access Control List (ACL) | Yes |
DHCP features | DHCP client |
SSH (SSL support) | Yes |
IGMP snooping | Yes |
Management features | |
Switch layer | L2+ |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch type | Managed |
Cloud-managed | Yes |
