Technical details | |
Vendor | Logitech |
Product type | Group video conferencing system |
Product colour | White |
Tilt angle range | -15 – 15 ° |
Pan range | -25 – 25 ° |
PTZ control | Y |
Packaging content | |
Remote control included | Y |
Cables included | AC, DC, HDMI, USB Type-A to USB Type-C |
HDMI cable length | 2 m |
Power cable length | 2.5 m |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Microphone in | Y |
Weight & dimensions | |
Height | 164 mm |
Width | 910 mm |
Depth | 160 mm |
Weight | 7080 g |
Features | |
Telepresence | N |
Interface module | |
Interface module HDMI ports quantity | 3 |
Interface module Ethernet LAN (RJ-45) ports | 1 |
Interface module HDMI input ports quantity | 1 |
Interface module HDMI output ports quantity | 2 |
Power | |
Current | 4.754 A |
AC input voltage | 100 – 240 V |
DC input voltage | 19 V |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Heat dissipation | 64 BTU/h |
Operating relative humidity (H-H) | 10 – 95 % |
Storage temperature (T-T) | -40 – 70 °C |
Network | |
Ethernet LAN | Y |
Wi-Fi | Y |
Ethernet LAN data rates | 10.100.1000 Mbit/s |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
Security algorithms | 128-bit AES |
Video | |
HD type | 4K Ultra HD |
Digital zoom | 3 x |
Supported video modes | 720p,900p,1440p,2160p |
Optical zoom | 5 x |
Maximum frame rate | 30 fps |
Microphone | |
Microphone frequency | 90 – 16000 Hz |
Microphone sensitivity | -36 dB |
Number of microphones | 6 |
Sound pressure level (max) | 90 dB |
Audio | |
Output level | 90/99 dB |
Built-in speaker(s) | Y |
Microphone pick-up range | 4.5 m |
Output voltage Total Harmonic Distortion (THD) | 2 % |
Camera | |
Remote control interface | Bluetooth |
Field of view (FOV) angle | 90 ° |
Horizontal field of view | 82.1 ° |
