Network | |
Auto-sensing | Y |
Networking standards | IEEE 802.11ad,IEEE 802.11az,IEEE 802.3ad,IEEE 802.3az |
Private VLAN | Y |
Flow control support | Y |
Port mirroring | Y |
Link aggregation | Y |
Rate limiting | Y |
DHCP client | Y |
DHCP server | Y |
IP routing | Y |
IGMP snooping | Y |
Auto MDI (MDI-X) | Y |
Spanning tree protocol | Y |
VLAN support | Y |
10G support | Y |
Cable types supported | Cat5, Cat5e, Cat6, Cat7, Fiber |
Technical details | |
Vendor | Netgear |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 50 |
USB 2.0 ports quantity | 1 |
SFP+ module slots quantity | 2 |
Console port | RJ-45/Mini-USB |
Optical fiber | |
Fiber optic connector | SFP+ |
Fiber ethernet cabling technology | 10GBASE-LR,10GBASE-LRM,10GBASE-SR |
Weight & dimensions | |
Height | 44 mm |
Width | 440 mm |
Depth | 388 mm |
Weight | 6670 g |
Design | |
LED indicators | Activity, Power, Speed |
Product colour | Black |
Case design | Freestanding |
Rack mounting | Y |
Safety | CSA 22.2 #950, UL 1950)/cUL IEC 950/EN 60950 |
Electromagnetic compatibility | CE, FCC 15 A, VCCI A, A EN 55022, (CISPR 22) A, EN 50082-1, EN 55024, |
Form factor | 1U |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) ports quantity | 48 |
Total Power over Ethernet (PoE) budget | 480 W |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet (PoE) | Y |
Performance | |
Packet buffer memory | 16 MB |
Auto-negotiation | Y |
Noise level | 39.8 dB |
Stackable | Y |
Processor frequency | 800 MHz |
Mean time between failures (MTBF) | 673207 h |
Flash memory | 256 MB |
Internal memory | 1024 MB |
Built-in processor | Y |
Power | |
Redundant power supply (RPS) support | Y |
Number of power supply units | 1 |
AC input voltage | 110-220 V |
Power consumption (max) | 865 W |
Power supply included | Y |
Operational conditions | |
Operating temperature (T-T) | 0 – 50 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Non-operating altitude | 0 – 3000 m |
Heat dissipation | 207913 BTU/h |
Operating altitude | 0 – 3000 m |
Operating relative humidity (H-H) | 0 – 90 % |
Storage temperature (T-T) | -20 – 70 °C |
Data transmission | |
Throughput | 357 Mpps |
Switching capacity | 128 Gbit/s |
Jumbo frames | 9000 |
Jumbo frames support | Y |
Store-and-forward | Y |
MAC address table | 16000 entries |
Number of VLANs | 4000 |
Packaging data | |
Rack mount kit | Y |
Cables included | AC, LAN (RJ-45), Mini-USB |
Resource CD | Y |
Rubber feet | Y |
User guide | Y |
Security | |
BPDU filtering (protection) | Y |
Access Control List (ACL) | Y |
Security algorithms | HTTPS,SNMP,SSH |
SSH (SSL support) | Y |
Management features | |
ARP inspection | Y |
Switch layer | L2/L3/L4 |
Quality of Service (QoS) support | Y |
Multicast support | Y |
Web-based management | Y |
Switch type | Managed network switch |
