Network | |
Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Flow control support | Yes |
Ethernet LAN data rates | 10.100.1000 Mbit/s |
10G support | No |
Technical details | |
Vendor | Netgear |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | AC-in jack |
Gigabit Ethernet (copper) ports quantity | 8 |
Weight & dimensions | |
Height | 27 mm |
Width | 236 mm |
Depth | 102 mm |
Weight | 600 g |
Design | |
LED indicators | Yes |
Wall mountable | Yes |
Product colour | Black, Grey |
Rack mounting | Yes |
Form factor | 1U |
Power over Ethernet (PoE) | |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Total Power over Ethernet (PoE) budget | 60 W |
Power over Ethernet (PoE) | Yes |
Performance | |
Buffer size | 192 KB |
Mean time between failures (MTBF) | 2752476 h |
Plug and Play | Yes |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Power | |
Power source | DC/PoE |
Input current | 1.25 A |
Power consumption (typical) | 67.5 W |
DC input voltage | 54 V |
Power consumption (max) | 130 W |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 0 – 95 % |
Heat dissipation | 230.85 BTU/h |
Operating altitude | 0 – 1000 m |
Operating relative humidity (H-H) | 0 – 90 % |
Storage temperature (T-T) | -20 – 70 °C |
Data transmission | |
Switching capacity | 16 Gbit/s |
Jumbo frames support | Yes |
Packet forwarding | Yes |
Store-and-forward | Yes |
MAC address table | 4000 entries |
Management features | |
Quality of Service (QoS) support | Yes |
Switch type | Unmanaged |
