Technical details | |
Vendor | QNAP |
Performance | |
Type | NAS |
Universal Plug and Play (UPnP) | Y |
Device class | Small & Medium Business |
Backup function | Y |
Backup features | Cloud, iSCSI LUN |
Noise level | 39 dB |
Built-in FTP server | Y |
System log | Y |
Hot spare | Y |
Share folder | CIFS/SMB |
Buzzer | Y |
Snapshot | Y |
Web-based management | Y |
USB copy function | Y |
Access Control List (ACL) | Y |
Reset button | Y |
Security algorithms | 256-bit AES,FIPS 140-2,HTTPS,SSH,SSL/TLS |
Multilingual support | Y |
On (off switch) | Y |
S.M.A.R.T. support | Y |
Browser supported | Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome |
Design | |
Chassis type | Rack (1U) |
LED indicators | HDD, LAN, Status |
Product colour | Black |
Number of fans | 2 fan(s) |
Cooling type | Active |
Fan diameter | 40 mm |
Storage | |
Number of storage drives supported | 4 |
Storage interfaces | Serial ATA |
Supported storage drive types | HDD, SSD |
RAID levels | 0,1,5,6,10,JBOD |
Storage drives installed | N |
Installed storage drive type | N |
Hot-swap drive bays | Y |
Supported file systems | FAT32,HFS+,NTFS,ext3,ext4 |
Online RAID migration | Y |
Online RAID expansion | Y |
Bad block scan | Y |
RAID rebuild | Y |
RAID support | Y |
Storage drive sizes supported | 2.5.3.5 ” |
Memory | |
Internal memory | 2 GB |
Maximum RAM supported | 16 GB |
Internal memory type | DDR4 |
Flash memory | 512 MB |
Memory slots | 1 |
Memory form factor | UDIMM |
Power | |
Redundant power supply (RPS) support | Y |
Fan voltage | 12 V |
Power supply unit (PSU) capacity | 250 W |
Power consumption (typical) | 53.343 W |
Number of power supply units | 2 |
AC input voltage | 100 – 240 V |
Power supply location | Built-in |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB port | Y |
Fiber ports quantity | 2 |
Fiber optic connector | SFP+ |
Software | |
Operating system | QNAP Turbo System |
Operating system version | 4.4.3 |
Windows operating systems supported | Windows 10,Windows 7,Windows 8 |
Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
Linux operating systems supported | Y |
Server operating systems supported | Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 |
Network | |
Ethernet LAN | Y |
Wake-on-LAN ready | Y |
Ethernet LAN data rate supported (max) | 10000 Mbit/s |
Link aggregation | Y |
Jumbo frames support | Y |
WLAN adapter supported | Y |
DHCP client | Y |
DHCP server | Y |
Ethernet LAN data rates | 100.1000.2500.10000 Mbit/s |
Supported network protocols | PPTP, L2TP/IPSec, OpenVPN, QBelt |
iSCSI support | Y |
Load balancing system | Y |
Processor | |
Processor manufacturer | Annapurna Labs |
Processor frequency | 1.7 GHz |
Processor family | Annapurna Labs |
Processor model | AL324 |
Processor cores | 4 |
Packaging content | |
Number of screws | 28 |
Cables included | AC, LAN (RJ-45) |
Weight & dimensions | |
Height | 44 mm |
Width | 439 mm |
Depth | 499 mm |
Package weight | 11120 g |
Weight | 8120 g |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Operating relative humidity (H-H) | 5 – 95 % |
