Technical details | |
Vendor | QNAP |
Performance | |
Type | NAS |
Device class | Small & Medium Business |
Backup function | Y |
Noise level | 20.3 dB |
Buzzer | Y |
Reset button | Y |
Security algorithms | AES |
On (off switch) | Y |
Design | |
Chassis type | Compact |
Kensington Lock | Y |
Cable lock slot type | Kensington |
LED indicators | HDD, LAN, Power, SSD, Status, USB |
Product colour | Black |
Built-in speaker(s) | N |
Fan diameter 2 | 92 mm |
Number of fans | 3 fan(s) |
Housing material | Metal |
Cooling type | Active |
Fan diameter | 60 mm |
Storage | |
Number of storage drives supported | 6 |
Storage interfaces | Serial ATA |
Storage drive interface | M.2, Serial ATA II, Serial ATA III |
Supported storage drive types | HDD, SSD |
Storage drives installed | N |
Installed storage drive type | N |
Hot-swap drive bays | Y |
Number of M.2 (M & B) slots | 2 |
Storage drive sizes supported | 2.5.3.5.M.2 ” |
Memory | |
Internal memory | 8 GB |
Maximum RAM supported | 64 GB |
ECC | Y |
Internal memory type | DDR4 |
Flash memory | 5000 MB |
Memory slots | 2 x SO-DIMM DDR4 |
Memory form factor | SO-DIMM |
Power | |
Redundant power supply (RPS) support | N |
Power supply unit (PSU) capacity | 250 W |
Power consumption (HDD standby) | 21.891 W |
Power consumption (typical) | 45.898 W |
Number of power supply units | 1 |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
PCI Express x4 (Gen 3.x) slots | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB port | Y |
Network | |
Ethernet LAN | Y |
Wake-on-LAN ready | Y |
Jumbo frames support | Y |
Ethernet LAN data rates | 100.1000.2500.5000 Mbit/s |
Processor | |
Processor manufacturer | AMD |
Processor frequency | 2.2 GHz |
Processor family | AMD Ryzen |
Processor model | V1500B |
Processor cores | 4 |
Number of processors supported | 1 |
Weight & dimensions | |
Height | 188.2 mm |
Width | 264.3 mm |
Depth | 280.8 mm |
Package weight | 7350 g |
Weight | 5780 g |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Operating relative humidity (H-H) | 5 – 95 % |
Storage temperature (T-T) | -20 – 70 °C |
