Technical details | |
Vendor | Synology |
Sustainability compliance | Y |
Sustainability certificates | CE, RoHS |
Performance | |
Type | NAS |
Device class | Small & Medium Business |
Backup function | Y |
Backup features | Cloud, iSCSI LUN |
Noise level | 40 dB |
Built-in FTP server | Y |
System log | Y |
Hot spare | Y |
Share folder | AFP, CIFS/SMB, FTP, WebDAV |
Snapshot | Y |
Web-based management | Y |
Access Control List (ACL) | Y |
Reset button | Y |
Security algorithms | HTTPS,SSH,SSL/TLS |
Management protocols | SNMP |
Multilingual support | Y |
On (off switch) | Y |
Browser supported | Safari, Chrome, Edge, Internet Explorer, Firefox |
Design | |
Chassis type | Rack (2U) |
LED indicators | HDD, Power, Status |
Drive bay locking | Y |
Product colour | Black |
Number of fans | 2 fan(s) |
Cooling type | Active |
Fan diameter | 80 mm |
Storage | |
Number of storage drives supported | 8 |
Storage interfaces | Serial ATA,Serial ATA II,Serial ATA III |
Supported storage drive types | HDD, SSD |
RAID levels | 5 |
Storage drives installed | N |
Installed storage drive type | N |
Hot-swap drive bays | Y |
Supported file systems | BTRFS,FAT,HFS+,NTFS,exFAT,ext3,ext4 |
Online RAID migration | Y |
Online RAID expansion | Y |
RAID support | Y |
Storage drive sizes supported | 2.5.3.5 ” |
Memory | |
Internal memory | 4 GB |
Maximum RAM supported | 32 GB |
ECC | Y |
Internal memory type | DDR4 |
Memory slots | 2 |
Memory form factor | SO-DIMM |
RAM capacity | 4 GB |
Power | |
Redundant power supply (RPS) support | Y |
Power supply unit (PSU) capacity | 350 W |
Power consumption (HDD standby) | 29.98 W |
Power consumption (typical) | 61.94 W |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
Power supply location | Built-in |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 4 |
PCI Express x8 (Gen 3.x) slots | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB port | Y |
eSATA ports quantity | 1 |
Software | |
Operating system | DiskStation Manager |
Windows operating systems supported | Y |
Mac operating systems supported | Y |
Network | |
Ethernet LAN | Y |
Wake-on-LAN ready | Y |
Link aggregation | Y |
Ethernet LAN data rates | 1000 Mbit/s |
Supported network protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN |
iSCSI support | Y |
Load balancing system | Y |
Processor | |
Processor manufacturer | AMD |
Processor frequency | 2.2 GHz |
Processor family | Ryzen Embedded |
Processor model | V1500B |
Processor cores | 4 |
Packaging content | |
Cables included | AC |
Power cables quantity | 2 |
Weight & dimensions | |
Height | 88 mm |
Width | 482 mm |
Depth | 407.5 mm |
Weight | 11700 g |
Operational conditions | |
Operating temperature (T-T) | 0 – 35 °C |
Operating altitude | 0 – 5000 m |
Operating relative humidity (H-H) | 5 – 95 % |
Storage temperature (T-T) | -20 – 60 °C |
