Processor | |
L3 cache | 8 MB |
Processor family | 1-CPU / Xeon UP |
Processor cores | 4-Core |
Processor frequency | 3.1 GHz |
Number of processors | 1 |
Maximum number of SMP processors | 1 |
Processor socket | LGA1200 |
Motherboard chipset | Intel C256 |
General | |
Processor model | Intel Xeon E-2324G / 3.1 GHz |
Operating system | Windows Server 2022 Standard |
Performance | |
Series | SERVER 3000 |
Compatible operating systems | Windows Server 2022 Windows Server 2019 |
Channels quantity | 8 (4x via mini-SAS HD port) 2x M.2 SATA/NVMe (22110/2280/2260/2242) |
Memory | |
Internal memory | 16 GB |
Maximum internal memory | 128 GB |
Internal memory type | DDR4 UDIMM with ECC |
Memory slots | 4x DDR4 PC3200/2933/2666, UB ECC |
Memory channels | Dual-Channel-Memory-Architecture |
Storage | |
Optical drive type | DVD±RW/±R |
RAID levels | RAID 6 |
Number of storage drives installed | 2 pc(s) |
Internal drive bays | 4x 3.5″/2.5″ optional 8x 3.5″/2.5″ |
Total storage capacity | 1920 GB |
SSD interface | SATA 6Gb/s |
HDD capacity | 2x 960 GB SSD |
Storage media type | SSD |
Design | |
Certification | CE, ISO 9001 |
Rack mounting | 5 |
Chassis type | Pedestal / Tower – optional modifiable |
Power | |
Number of redundant power supplies supported | 2 |
Number of redundant power supplies installed | 1 |
Power source | Power supply |
Redundant power supply (RPS) support | Optional |
Maximum input power | 650 Watt |
AC adapter input voltage | 100-240 V~ (Auto Full Range), 6-3 A, 50-60 Hz |
Mouse | |
Mouse included | Optional |
Keyboard | |
Keyboard form factor | Optional |
Network | |
Ethernet LAN | Integrated |
LAN controller | 2x Intel I210AT |
Cabling technology | 2x 1 GbE (RJ45) |
Other features | |
Number of drive bays | 1x PCIe 4.0 x16 (x16/x8 link) 1x PCIe 4.0 x8 2x PCIe 3.0 x8 (x4 link) |
Drive bays | 3x 5.25″ ( 1 pc occupied) |
Interface | 1x PS/2 keyboard/mouse 1x VGA (functional only with ASMB10-iKVM module) 1x HDMI (functional only with Xeon E-23xxG CPUs) 2x LAN (RJ-45) 1x Mgmt LAN 2x USB 3.2 Gen2 4x USB 3.2 Gen1 (2x front) option: 1x serial |
Motherboard manufacturer | Asus P12R-E |
Remote administration | Yes |
Hard disk controller | onboard-controller |
Technical details | |
Localization | International |
Optional on-site service | 24h On-Site-Service + DMR |
Weight & dimensions | |
Height | 42.5 cm |
Width | 22 cm |
Depth | 66 cm |
Cooling | |
Cooling type | Active |
Graphics | |
Graphics adapter ports | 1x VGA 1x HDMI (functional only with Xeon E-23xxG CPUs) |
Maximum graphics adapter memory | 64 MB |
Graphics card | Aspeed AST2600 |
Operational conditions | |
Operating temperature (T-T) | 10 °C – 35 °C (recommendation: 20 °C – 22 °C) |
Recommended humidity operating range | 10-75% (non-condensing) |
TERRA SERVER 3330 G5 (BTO)
5.559,78 € με ΦΠΑ
TERRA SERVER 3130 G5 (BTO)
3.464,18 € με ΦΠΑ
TERRA SERVER 3530 G5 (BTO)
3.415,82 € με ΦΠΑ
- Intel Xeon E-2324G / 3.1 GHz
- Windows Server 2022 Standard
- SERVER 3000 Series
- 3.1 GHz Processor frequency
- Number of processors 1
- 16 GB Internal memory
- HDD capacity 2x 960 GB SSD
- onboard-controller
Διαθέσιμο κατόπιν παραγγελίας
Διαθέσιμο Παράδοση 4 έως 10 εργάσιμες ημέρες
Περιγραφή
Επιπλέον πληροφορίες
Βάρος | 30 kg |
---|
Κωδικός προϊόντος:
1100263
Κατηγορία: SERVER
