Network | |
Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
Flow control support | Y |
Full duplex | Y |
Auto MDI (MDI-X) | Y |
10G support | N |
Technical details | |
Vendor | TP-LINK |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
DC-in jack | Y |
Gigabit Ethernet (copper) ports quantity | 5 |
Other features | |
Networking features | Gigabit Ethernet |
Connectivity technology | Wired |
Ethernet LAN (RJ-45) ports | 5 |
Dimensions (WxDxH) | 165 x 108 x 28 mm |
Design | |
Product colour | Black |
Certification | FCC, CE, RoHs |
Rack mounting | N |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) | N |
Performance | |
Stackable | N |
Power | |
Power consumption (typical) | 3 W |
AC input frequency | 50/60 Hz |
AC input voltage | 100-240 V |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Switching capacity | 16 Gbit/s |
Maximum data transfer rate | 1 Gbit/s |
Jumbo frames support | Y |
Store-and-forward | Y |
Supported data transfer rates | 10/100/1000 Mbit/s |
Management features | |
Switch type | Unmanaged network switch |
