Network | |
Networking standards | IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
Flow control support | Y |
Port mirroring | Y |
Link aggregation | Y |
Broadcast storm control | Y |
Rate limiting | Y |
Full duplex | Y |
IGMP snooping | Y |
Auto MDI (MDI-X) | Y |
VLAN support | Y |
10G support | N |
Technical details | |
Vendor | TP-LINK |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Weight & dimensions | |
Height | 44 mm |
Width | 294 mm |
Depth | 180 mm |
Design | |
LED indicators | Y |
Product colour | Black |
Certification | FCC, CE, RoHS |
Rack mounting | Y |
Performance | |
Packet buffer memory | 0.5 MB |
Power | |
AC input frequency | 50/60 Hz |
AC input voltage | 100-240 V |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Throughput | 23.8 Mpps |
Switching capacity | 32 Gbit/s |
Jumbo frames support | Y |
Number of queues | 4 |
Store-and-forward | Y |
MAC address table | 8000 entries |
Number of VLANs | 32 |
Packaging data | |
User guide | Y |
System requirements | |
Compatible operating systems | Windows 98SE, NT, 2000, XP, Vista Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
Management features | |
Switch layer | L2 |
Quality of Service (QoS) support | Y |
Switch type | Managed network switch |
