Network | |
Auto-negotiation | Y |
Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x |
Flow control support | Y |
Port mirroring | Y |
Link aggregation | Y |
Broadcast storm control | Y |
Rate limiting | Y |
Virtual LAN features | Port-based VLAN,Tagged VLAN |
Full duplex | Y |
Auto MDI (MDI-X) | Y |
Number of VLANs | 4000 |
VLAN support | Y |
10G support | N |
Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
Cable types supported | Cat3,Cat4,Cat5,Cat5e,Cat6 |
Technical details | |
Vendor | TP-LINK |
Ports & interfaces | |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 16 |
Gigabit Ethernet (copper) ports quantity | 16 |
Weight & dimensions | |
Height | 44 mm |
Width | 294 mm |
Depth | 180 mm |
Design | |
LED indicators | Y |
Product colour | Black |
Certification | FCC, CE, RoHS |
Stackable | N |
Number of fans | 1 fan(s) |
Rack mounting | Y |
Power over Ethernet (PoE) | |
Power over Ethernet plus (PoE+) ports quantity | 8 |
Total Power over Ethernet (PoE) budget | 110 W |
Power over Ethernet (PoE) power per port | 30 W |
Power over Ethernet (PoE) | Y |
Power | |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
Power consumption (max) | 124.4 W |
Power supply included | Y |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Data transmission | |
Throughput | 23.8 Mpps |
Switching capacity | 32 Gbit/s |
Jumbo frames | 1000 |
Jumbo frames support | Y |
Number of queues | 4 |
Store-and-forward | Y |
MAC address table | 8000 entries |
Packaging data | |
Rack mount kit | Y |
Cables included | AC |
Security | |
Loop protection | Y |
Static port security | Y |
IGMP snooping | Y |
Management features | |
Quality of Service (QoS) support | Y |
Web-based management | Y |
Switch type | Managed |
