Network | |
Cabling technology | 10/100Base-T(X) |
Ethernet LAN | Y |
Receiver sensitivity | 11g 54M: -74dBm 11n HT20: -71dBm 11n HT40: -67dBm |
Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n) | 20 dBmW |
Ethernet LAN interface type | Fast Ethernet |
Ethernet LAN data rates | 10.100 Mbit/s |
Port triggering | Y |
Wireless radio | Y |
Technical details | |
Vendor | TP-LINK |
Packaging content | |
AC adapter included | Y |
Cables included | LAN (RJ-45) |
Quick installation guide | Y |
Ports & interfaces | |
Memory card slot(s) | N |
Ethernet LAN (RJ-45) ports | 2 |
DC-in jack | Y |
USB port | N |
Antenna | |
Antenna connector type | N-type |
Antenna design | External |
Antennas quantity | 2 |
Weight & dimensions | |
Height | 36 mm |
Width | 154 mm |
Depth | 114 mm |
Design | |
Product type | Tabletop router |
Product colour | Black |
On (off switch) | Y |
Mobile network | |
4G bands supported | 800.900.1800.1900.2100.2300.2500.2600 MHz |
4G | Y |
4G standard | LTE-TDD & LTE-FDD |
mobile standards | HSPA, UMTS |
Mobile network generation | 4G |
3G | Y |
UMTS bands supported | 850.900.2100 MHz |
Features | |
Firmware upgradeable | Y |
Logistics data | |
Harmonized System (HS) code | 85176990 |
WAN connection | |
WAN connection type | RJ-45 |
DSL WAN | Y |
Ethernet WAN | Y |
SIM card slot | Y |
3G (4G USB modem compatibility) | Y |
Power | |
Output voltage | 9 V |
Output current | 0.85 A |
Power source type | DC |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Protocols | |
Universal Plug and Play (UPnP) | Y |
DHCP client | Y |
DHCP server | Y |
Supported network protocols | IPv4, IPv6 |
Security | |
Firewall | Y |
Guest access | Y |
MAC address filtering | Y |
Stateful Packet Inspection (SPI) | Y |
Schedule access | Y |
Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
DMZ support | Y |
IP address filtering | Y |
System requirements | |
Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
Windows operating systems supported | Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Mac operating systems supported | Y |
Linux operating systems supported | Y |
Wireless LAN features | |
Wi-Fi band | Single-band (2.4 GHz) |
WLAN data transfer rate (max) | 300 Mbit/s |
Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Management features | |
Wi-Fi Multimedia (WMM) ((WME)) | Y |
Quality of Service (QoS) support | Y |
Reset button | Y |
Wireless statistics | Y |
WPS push button | Y |
