Technical details | |
Vendor | TP-LINK |
Packaging content | |
Cables included | AC |
Mounting kit | Y |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
Antenna | |
Antenna type | dual-polarized directional MIMO |
Antenna gain level (max) | 9 dBi |
Integrated antenna | Y |
Antennas quantity | 1 |
Detachable antenna(s) | N |
Weight & dimensions | |
Height | 60 mm |
Width | 224 mm |
Depth | 79 mm |
Other features | |
Transmit power range | 0 – 27 dBmW |
Design | |
LED indicators | Y |
Product colour | White |
Internal | N |
International Protection (IP) code | IPX5 |
Performance | |
Maximum data transfer rate | 300 Mbit/s |
Receiver sensitivity | 802.11b:\n11M: -95dBm, 5.5M: -96dBm, 2M: -96dBm, 1M: -96dBm\n-802.11g:\n54M: -79dBm, 48M: -80dBm, 36M: -84dBm, 6-24M: -88dBm\n802.11n:\nMCS15: -76dBm, MCS14: -78dBm, MCS13: -80dBm,\nMCS12: -84dBm, MCS11: -87dBm, MCS10: -91dBm,\nMCS9: -93dBm, MCS8: -96dBm, MCS7: -76dBm,\nMCS6: -78dBm, MCS5: -80dBm, MCS4: -84dBm,\nMCS3: -87dBm, MCS2: -91dBm, MCS1: -93dBm, MCS0: -96dBm |
Bandwidth | 2.4 GHz |
Frequency band | 2.4 – 2.483 GHz |
Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
2.4 GHz | Y |
Certification | – FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark\n- RoHS, IPX5 |
Wi-Fi data rate (max) | 300 Mbit/s |
Web-based management | Y |
Reset button | Y |
Flash memory | 8 MB |
Internal memory | 64 MB |
Management platform | PharOS |
Maximum outdoor range | 15000 m |
Power | |
Input voltage | 100-240 V |
Output voltage | 24 V |
Input frequency | 50 – 60 Hz |
Power over Ethernet (PoE) | Y |
Input current | 0.8 A |
Output current | 1 A |
Power consumption (max) | 10.5 W |
Operational conditions | |
Operating temperature (T-T) | -30 – 70 °C |
Storage relative humidity (H-H) | 5 – 95 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Protocols | |
Management protocols | TDMA |
Security | |
MAC address filtering | Y |
Security algorithms | 128-bit WEP,152-bit WEP,64-bit WEP,SSID,TKIP,WPA,WPA-PSK,WPA2,WPA2-PSK |
System requirements | |
Compatible operating systems | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. |
