Network | |
Networking standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Technical details | |
Vendor | TP-LINK |
Ethernet LAN features | |
Ethernet LAN | Y |
Ethernet LAN interface type | Fast Ethernet |
Ethernet LAN data rates | 10.100 Mbit/s |
Cabling technology | 10/100Base-T(X) |
Packaging content | |
Manual | Y |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Y |
Antenna | |
Antenna type | Internal |
Weight & dimensions | |
Height | 18 mm |
Width | 57 mm |
Depth | 57 mm |
Other features | |
USB ports quantity | 1 |
Frequency band | 2.4 GHz |
Mobile network connection | N |
xDSL connection | N |
WLAN data transfer rates supported | 11.54.300 Mbit/s |
Supported WAN type | IP, Static IP, PPPoE, PPTP, L2TP |
Rack mounting | N |
Frequency range | 2.4 – 2.4835 GHz |
Design | |
LED indicators | Y |
Product colour | Blue, White |
On (off switch) | Y |
Mobile network | |
4G | N |
3G | N |
WAN connection | |
Ethernet WAN | Y |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Protocols | |
DHCP client | Y |
DHCP server | Y |
DMZ support | Y |
Security | |
Firewall | Y |
Firewall security | DoS, SPI |
VPN support | PPTP, L2TP, IPSec |
MAC address filtering | Y |
Security algorithms | 128-bit WEP,152-bit WEP,64-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
IP address filtering | Y |
Certificates | |
Certification | CE, FCC, RoHS |
Software | |
Windows operating systems supported | Windows 2000,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows 98SE,Windows NT,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 |
Mac operating systems supported | Y |
Linux operating systems supported | Y |
Wireless LAN features | |
Wi-Fi band | N |
WLAN data transfer rate (max) | 300 Mbit/s |
Top Wi-Fi standard | IEEE 802.11n |
Wi-Fi standards | IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Management features | |
Universal Plug and Play (UPnP) | Y |
Web-based management | Y |
Reset button | Y |
