Network | |
Cabling technology | 10/100Base-T(X) |
Ethernet LAN | Y |
Receiver sensitivity | 11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9: -61.5dBm 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
VPN support | PPTP, L2TP, IPSec |
Dynamic DNS (DDNS) | Y |
Ethernet LAN interface type | Fast Ethernet |
VPN Passthrough | Y |
Ethernet LAN data rates | 10.100 Mbit/s |
Port triggering | Y |
Port forwarding | Y |
Technical details | |
Vendor | TP-LINK |
Packaging content | |
AC adapter included | Y |
Cables included | LAN (RJ-45), USB |
Quick start guide | Y |
Ports & interfaces | |
Memory card slot(s) | N |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
DC-in jack | Y |
USB port | Y |
Antenna | |
Transmit power | CE: |
Antenna design | Internal |
Receive power | 11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9: -61.5dBm. 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm dBmW |
Weight & dimensions | |
Height | 22 mm |
Width | 74 mm |
Depth | 67 mm |
Design | |
Product type | Portable router |
Product colour | White |
Mobile network | |
4G | Y |
Mobile network generation | 4G |
3G | Y |
Logistics data | |
Harmonized System (HS) code | 85176990 |
WAN connection | |
DSL WAN | N |
Ethernet WAN | Y |
SIM card slot | N |
3G (4G USB modem compatibility) | N |
Power | |
Output voltage | 5 V |
Output current | 2 A |
Power source type | AC |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Protocols | |
Universal Plug and Play (UPnP) | Y |
DHCP client | Y |
DHCP server | Y |
Supported network protocols | -40 – 70 |
Security | |
Firewall | Y |
URL filtering | Y |
Firewall security | SPI |
Guest access | Y |
Filtering | Y |
Stateful Packet Inspection (SPI) | Y |
Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS |
DMZ support | Y |
IP address filtering | Y |
DoS attack prevention | Y |
System requirements | |
Windows operating systems supported | Y |
Mac operating systems supported | Y |
Linux operating systems supported | Y |
Mac compatibility | Y |
Wireless LAN features | |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) | 733 Mbit/s |
WLAN data transfer rate (first band) | 300 Mbit/s |
WLAN data transfer rate (second band) | 433 Mbit/s |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac) |
Management features | |
Quality of Service (QoS) support | Y |
Reset button | Y |
WPS push button | Y |
