Technical details | |
Vendor | TP-LINK |
Packaging content | |
AC adapter included | Y |
Number of products included | 5 pc(s) |
Mounting kit | Y |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
DC-in jack | Y |
Antenna | |
Antenna type | Internal |
Antenna gain level (max) | 4 dBi |
Antenna features | Integrated antenna |
Antenna direction type | Omni-directional |
Weight & dimensions | |
Height | 37 mm |
Width | 206 mm |
Depth | 182 mm |
Design | |
LED indicators | Y |
Product colour | White |
Certification | CE, FCC, RoHS |
Reset button | Y |
Placement | Ceiling, Wall |
Features | |
Maximum data transfer rate | 1750 Mbit/s |
Transmitting power | 27 dBmW |
Frequency band | 2.4. 5 GHz |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af |
2.4 GHz | Y |
5 GHz | Y |
Wireless isolation | Y |
Wi-Fi Multimedia (WMM) ((WME)) | Y |
MIMO | Y |
Quality of Service (QoS) support | Y |
Wi-Fi roaming | Y |
Band steering | Y |
Airtime Fairness (ATF) | Y |
MIMO type | Multi User MIMO |
Rate limiting | Y |
Ethernet LAN data rates | 10.100.1000 Mbit/s |
Virtual LAN features | SSID-based VLAN assignment |
Maximum data transfer rate (2.4 GHz) | 450 Mbit/s |
Maximum data transfer rate (5 GHz) | 1300 Mbit/s |
Automatic channel selection | Y |
VLAN support | Y |
Cabling technology | 10/100/1000Base-T(X) |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Power | |
Power over Ethernet (PoE) | Y |
Input current | 1.5 A |
Power consumption (typical) | 12.3 W |
AC input voltage | 48 V |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Security | |
Number of SSID supported | 16 |
MAC address filtering | Y |
Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
Management features | |
Web-based management | Y |
Syslog | Y |
