Technical details | |
Vendor | TP-LINK |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 4 |
Antenna | |
Antenna type | Internal |
Weight & dimensions | |
Height | 20 mm |
Width | 143 mm |
Depth | 86 mm |
Design | |
LED indicators | Power |
Product colour | White |
Certification | CE, FCC, RoHS |
Reset button | Y |
On (off switch) | Y |
Placement | Wall |
Features | |
Maximum data transfer rate | 1774 Mbit/s |
Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
2.4 GHz | Y |
5 GHz | Y |
MIMO | Y |
Quality of Service (QoS) support | Y |
Automatic channel scanning | Y |
Band steering | Y |
Airtime Fairness (ATF) | Y |
MIMO type | Multi User MIMO |
Rate limiting | Y |
Ethernet LAN data rates | 10.100.1000 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
Transmitting power (FCC) | 21 dBm |
Transmitting power (CE) | 20 dBm |
Automatic channel selection | Y |
VLAN support | Y |
Cabling technology | 10/100/1000Base-T(X) |
Power | |
Power over Ethernet (PoE) | Y |
Operational conditions | |
Operating temperature (T-T) | 0 – 40 °C |
Storage relative humidity (H-H) | 5 – 90 % |
Operating relative humidity (H-H) | 10 – 90 % |
Storage temperature (T-T) | -40 – 70 °C |
Protocols | |
STelnet using SSH v2 | Y |
Security | |
Number of SSID supported | 16 |
Access Control List (ACL) | Y |
Remote Authentication Dial-In User Service (RADIUS) | Y |
Service Set Identifier (SSID) features | Multiple SSIDs |
Security algorithms | WPA,WPA2,WPA3 |
Management features | |
Syslog | Y |
