Network | |
Ethernet LAN | Y |
Bluetooth | N |
Wi-Fi | N |
Ethernet interface | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
Technical details | |
Vendor | Ubiquiti Networks |
Sustainability compliance | Y |
Sustainability certificates | CE, Federal Communications Commission (FCC) |
Packaging content | |
Number of cameras | 1 |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 1 |
Lens system | |
Number of lenses | 1 |
Weight & dimensions | |
Length | 74.4 mm |
Diameter | 75.5 mm |
Weight | 225 g |
Design | |
IK code | IK04 |
Product colour | Black, White |
Housing material | Aluminium, Polycarbonate (PC) |
Mounting type | Wall/Pole |
Form factor | Bullet |
International Protection (IP) code | IPX4 |
Night vision | |
LED type | IR |
Night vision | Y |
Performance | |
Connectivity technology | Wired |
Infrared (IR) cut-off filter | Y |
Placement supported | Indoor & outdoor |
Processor model | ARM Cortex-A7 |
Built-in processor | Y |
Power | |
DC output voltage | 57 |
Power source type | PoE |
Power consumption (max) | 4 W |
Operational conditions | |
Operating temperature (T-T) | -20 – 40 °C |
Operating relative humidity (H-H) | 0 – 90 % |
Video | |
Maximum resolution | 2688 x 1512 pixels |
Privacy masking | Y |
Text caption overlay | Y |
Video compression formats | H.264, M-JPEG |
Noise reduction | Y |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Frame rate | 30 fps |
Supported graphics resolutions | 2688 x 1512 |
Supported video modes | 1512p |
Total megapixels | 5 MP |
Image quality adjustment | Brightness, Contrast, Sharpness |
Image sensor | |
Sensor type | CMOS |
Audio | |
Built-in microphone | Y |
Management features | |
Reset button | Y |
Management software | UniFi Protect |
Camera | |
Lens viewing angle, horizontal | 84.4 ° |
Lens viewing angle, vertical | 45.4 ° |
Lens viewing angle, diagonal | 99.8 ° |
