Network | |
Auto-sensing | Y |
Networking standards | IEEE 802.3af,IEEE 802.3at |
Flow control support | Y |
Port mirroring | Y |
Full duplex | Y |
Auto MDI (MDI-X) | Y |
Spanning tree protocol | Y |
VLAN support | Y |
10G support | Y |
Technical details | |
Vendor | Ubiquiti Networks |
Ports & interfaces | |
Installed SFP+ modules quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Weight & dimensions | |
Height | 43.7 mm |
Width | 442.4 mm |
Depth | 285.4 mm |
Weight | 4300 g |
Design | |
LED indicators | Activity, Link, PoE, Speed, System |
Product colour | Silver |
Certification | CE, FCC, IC |
Rack mounting | Y |
Form factor | 1U |
Power over Ethernet (PoE) | |
Power over Ethernet plus (PoE+) ports quantity | 16 |
Total Power over Ethernet (PoE) budget | 400 W |
Power over Ethernet (PoE) power per port | 64 W |
Power over Ethernet (PoE) | Y |
Power | |
Input current | 7.69 A |
Number of power supply units | 1 |
AC input frequency | 50/60 Hz |
AC input voltage | 100 – 240 V |
DC input voltage | 52 V |
Power supply included | Y |
Operational conditions | |
Operating temperature (T-T) | -5 – 40 °C |
Operating relative humidity (H-H) | 10 – 90 % |
Data transmission | |
Throughput | 44000 Mpps |
Switching capacity | 88 Gbit/s |
Jumbo frames support | Y |
Static route | Y |
Forwarding rate | 65.472 Mpps |
Security | |
Authentication type | IEEE 802.1x,RADIUS |
DHCP features | DHCP server |
Management features | |
Switch layer | L2/L3 |
Switch type | Managed |
