Network | |
Flow control support | Yes |
Port mirroring | Yes |
Broadcast storm control | Yes |
Rate limiting | Yes |
10G support | No |
Copper ethernet cabling technology | 2.5GBASE-T |
Technical details | |
Vendor | Ubiquiti Networks |
Ports & interfaces | |
Installed SFP+ modules quantity | 0 |
Installed SFP modules quantity | 0 |
Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
Power connector | USB |
USB Type-C ports quantity | 1 |
2.5G Ethernet (copper) ports quantity | 5 |
Weight & dimensions | |
Height | 21.2 mm |
Width | 117.1 mm |
Depth | 90 mm |
Weight | 206 g |
Other features | |
Networking features | STP / RSTP with priorities and port-level disable, Egress rate limit |
Design | |
LED indicators | Activity, Power, Progress |
Product colour | White |
Reset button | Yes |
Housing material | Polycarbonate (PC) |
Form factor | Desktop |
Power over Ethernet (PoE) | |
Power over Ethernet (PoE) power per port | 6.4 W |
Power over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) voltage | 57 V |
Performance | |
Minimum system requirements | UniFi Network Version 8.4.62 and later |
Multicast features | |
Multicast support | Yes |
Power | |
Power plug type | Type A |
Power source | AC/DC/PoE |
Input current | 1 A |
DC input voltage | 5 V |
Power consumption (max) | 5 W |
Power supply included | Yes |
Operational conditions | |
Operating temperature (T-T) | -20 – 45 °C |
Operating relative humidity (H-H) | 10 – 90 % |
Data transmission | |
Switching capacity | 25 Gbit/s |
Jumbo frames support | Yes |
Throughput | 12.5 Gbit/s |
Forwarding rate | 18.6 Mpps |
Packaging data | |
AC adapter included | Yes |
Certificates | |
Certification | CE, FCC, IC |
Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
Management features | |
Switch type | Managed |
